Connor-Winfield宣布推出符合ITU-T G.8262的新TCXO6G晶振,TL602-010.0M,伊利諾伊州奧羅拉–TL602和ML602是溫度補償晶體振蕩器（TCXO晶振）石英晶振型號，專門設計用于與0.1Hz配合使用（更高）濾波器帶寬，符合基于T1的層次結構規范如ITU-TG.8262選項1和2ECC以及ITU-TG.813選項1和2SEC，用于Sonet、IEEE1588和同步以太網的第3層。ConnorWinfield晶振的TCXO生產線利用模擬溫度補償，具有出色的短期穩定性特性。TL602和ML602這兩款TCXO在工業溫度范圍為-40至+85℃。它們也是小型的出色頻率產品的參考選擇例如蜂窩網絡、無線應用設備和儀器儀表應用。

Connor-Winfield announces new ITU-T G.8262 compliant TCXO6G crystal oscillator,TL602-010.0M, Aurora, IL - TL602 and ML602 are temperature compensated crystal oscillator (TCXO crystal oscillator)  crystal oscillator models. Specifically designed for use with 0.1Hz (higher) filter bandwidth-compliant with T1-based hierarchy specifications such as ITU-TG.8262 Options 1 and 2ECC and ITU-TG.813 Options 1 and 2SEC for Sonet, IEEE1588 and Layer 3 of Synchronous Ethernet. ConnorWinfield's TCXO line utilizes simulated temperature compensation for excellent short-term stability. The two TCXOs, TL602 and ML602, have an industrial temperature range of -40 to +85 ° C. They are also the reference choice for small, excellent frequency products such as cellular networks, wireless applications, and instrumentation applications.

特征：可用頻率為10MHz、12.8MHz、19.2MHz、19.44MHz、20MHz和24.576MHz。LVCMOS或削波正弦波，固定輸出或電壓控制，符合在.1Hz帶寬下測量的MTIE和TDEV模板在整個工業溫度范圍內具有280ppb峰峰值溫度穩定性。在12kHz-20MHz頻段內低于300ps的抖動性能，使用精度為±4.6ppm，完全符合ROHS和REACH標準，7x5毫米（TL602）或5x3.2毫米（ML602）SMD晶振封裝選項。

Features: Available frequencies are 10MHz, 12.8MHz, 19.2MHz, 19.44MHz, 20MHz and 24.576MHz. LVCMOS or clipped sine wave, fixed output or voltage control, conforming to the MTIE and TDEV templates measured at a bandwidth of.1Hz with 280ppb peaking temperature stability over the entire industrial temperature range. Jitter performance below 300ps in the 12kHz-20MHz band, accuracy of ±4.6ppm in use, full ROHS and REACH compliance, 7x5 mm (TL602) or 5x3.2 mm (ML602) package options.
