DSC1124CI2-156.2500,HCSL差分晶振,Microchip微芯晶振,高穩定性晶振
頻率：156.25MHz
尺寸：3.20mm x 2.50mm
DSC1124CI2-156.2500,HCSL差分晶振,Microchip微芯晶振,高穩定性晶振,作為Microchip旗下高穩定性晶振代表,DSC1124CI2-156.2500依托微芯成熟的晶振制造工藝,在溫度穩定性上表現卓越,寬溫工作范圍內(通常覆蓋-40℃至85℃工業級溫度)頻率偏差極小,可低至±25ppm甚至更優水平;同時具備低功耗特性,靜態電流控制在極低范圍,能減少設備整體功耗,延長便攜式或低功耗設備的續航時間,是兼顧穩定性與節能需求的理想選擇.
訂購熱線：0755-27837162
DSC1124CI2-156.2500,HCSL差分晶振,Microchip微芯晶振,高穩定性晶振
DSC1124CI2-156.2500晶振承載Microchip測試設備晶振品牌嚴苛的品質管控體系,從原材料篩選到生產流程均經過多重檢測驗證,符合RoHS等環保標準,確保產品無有害物質,適配綠色電子設備需求;微芯完善的供應鏈與技術支持體系,能為客戶提供從樣品測試到批量生產的全周期服務,解決應用過程中的技術難題,保障設備穩定運行,降低客戶使用風險.在5G基站,數據中心交換機等設備中,其穩定的時鐘信號能保障高速數據傳輸?shù)耐叫?在工業自動化控制系統中,寬溫特性與抗干擾能力可適應復雜工業環境;同時也適用于高端測試儀器,為精準測量提供可靠時鐘支撐.
DSC1124CI2-156.2500,HCSL差分晶振,Microchip微芯晶振,高穩定性晶振
| 原廠型號 Originalmodel： | DSC1124CI2-156.2500 | 品牌brand： | Microchip有源晶振 |
| Manufacturer品牌 | Microchip有源晶振 | OperatingTemperature溫度 | -40°C ~ 85°C |
| Series型號 | DSC1124 | Current-Supply(Max) | 42mA |
| Type類型 | MEMS晶振 | PackageHeight高度 | 0.90mm |
| Frequency頻率 | 156.25MHz | Termination 腳位 | 6pad |
| 輸出方式 Output： | HCSL | PackageType 封裝類型 | 6-SMD |
| Voltage-Supply電壓 | 2.25 V ~ 3.6 V | Packaging 包裝 | TapeandReel |
| FrequencyStability頻率穩定度 | ±25ppm | 安裝方式 Installation： | Surfacemount |
| Size/Dimension尺寸 | 3.20mm x 2.50mm | 最小包裝數MPQ： | 3000 |
DSC1124CI2-156.2500,HCSL差分晶振,Microchip微芯晶振,高穩定性晶振
DSC1124CI2-156.2500,HCSL差分晶振,Microchip微芯晶振,高穩定性晶振
| DSC1123CI2-125.0000 | Microchip有源晶振 | DSC1123 | MEMS | 125MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1123CI2-200.0000 | Microchip有源晶振 | DSC1123 | MEMS | 200MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1123AE2-100.0000 | Microchip有源晶振 | DSC1123 | MEMS | 100MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1001CI2-027.0000 | Microchip有源晶振 | DSC1001 | MEMS | 27MHz | CMOS | 1.8 V ~ 3.3 V |
| DSC1123CE1-156.2500 | Microchip有源晶振 | DSC1123 | MEMS | 156.25MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1123CI2-150.0000 | Microchip有源晶振 | DSC1123 | MEMS | 150MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1123CI2-100.0000 | Microchip有源晶振 | DSC1123 | MEMS | 100MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1103DI2-312.5000 | Microchip有源晶振 | DSC1103 | MEMS | 312.5MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1123DI2-050.0000 | Microchip有源晶振 | DSC1123 | MEMS | 50MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1123CI2-156.2500 | Microchip有源晶振 | DSC1123 | MEMS | 156.25MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1123BL2-125.0000 | Microchip有源晶振 | DSC1123 | MEMS | 125MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1123CI5-125.0000 | Microchip有源晶振 | DSC1123 | MEMS | 125MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1103CI5-300.0000 | Microchip有源晶振 | DSC1103 | MEMS | 300MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1123DL5-200.0000 | Microchip有源晶振 | DSC1123 | MEMS | 200MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1123NL5-100.0000 | Microchip有源晶振 | DSC1123 | MEMS | 100MHz | LVDS | 2.25 V ~ 3.6 V |
| MX574BBD322M265 | Microchip有源晶振 | MX57 | XO (Standard) | 322.265625MHz | HCSL | 2.375 V ~ 3.63 V |
| DSC1001CI2-018.4320 | Microchip有源晶振 | DSC1001 | MEMS | 18.432MHz | CMOS | 1.8 V ~ 3.3 V |
| DSC1123CI1-200.0000 | Microchip有源晶振 | DSC1123 | MEMS | 200MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1123CI1-156.2500 | Microchip有源晶振 | DSC1123 | MEMS | 156.25MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1123AE2-300.0000 | Microchip有源晶振 | DSC1123 | MEMS | 300MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1123AI1-125.0000 | Microchip有源晶振 | DSC1123 | MEMS | 125MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1123AI2-125.0000 | Microchip有源晶振 | DSC1123 | MEMS | 125MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1122CE1-125.0000 | Microchip有源晶振 | DSC1122 | MEMS | 125MHz | LVPECL | 2.25 V ~ 3.6 V |
| DSC1123AE2-200.0000 | Microchip有源晶振 | DSC1123 | MEMS | 200MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1103CI1-075.0000 | Microchip有源晶振 | DSC1103 | MEMS | 75MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1123AI2-150.0000 | Microchip有源晶振 | DSC1123 | MEMS | 150MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC1123AI1-200.0000 | Microchip有源晶振 | DSC1123 | MEMS | 200MHz | LVDS | 2.25 V ~ 3.6 V |
| DSC557-0344SI1 | Microchip有源晶振 | DSC557-03 | MEMS | 100MHz | HCSL | 2.25 V ~ 3.6 V |
| DSC6003CI1A-033.0000 | Microchip有源晶振 | DSC60XX | MEMS | 33MHz | CMOS | 1.71 V ~ 3.63 V |
| DSC6111CI1A-008.0000 | Microchip有源晶振 | DSC6100 | MEMS | 8MHz | CMOS | 1.71 V ~ 3.63 V |
| DSC6011JI1A-024.0000 | Microchip有源晶振 | DSC60XX | MEMS | 24MHz | CMOS | 1.71 V ~ 3.63 V |
| DSC6083CI2A-032K800 | Microchip有源晶振 | DSC60XX | MEMS | 32.8kHz | CMOS | 1.71 V ~ 3.63 V |
| DSC6083CI2A-307K000 | Microchip有源晶振 | DSC60XX | MEMS | 307kHz | CMOS | 1.71 V ~ 3.63 V |
| DSC6001CI2A-004.0000 | Microchip有源晶振 | DSC60XX | MEMS | 4MHz | CMOS | 1.71 V ~ 3.63 V |
| DSC6001CI2A-032.0000 | Microchip有源晶振 | DSC60XX | MEMS | 32MHz | CMOS | 1.71 V ~ 3.63 V |
| DSC6083CI2A-250K000 | Microchip有源晶振 | DSC60XX | MEMS | 250kHz | CMOS | 1.71 V ~ 3.63 V |
| DSC6083CI2A-002K000 | Microchip有源晶振 | DSC60XX | MEMS | 2kHz | CMOS | 1.71 V ~ 3.63 V |
| DSC6101JI2A-024.0000 | Microchip有源晶振 | DSC6100 | MEMS | 24MHz | CMOS | 1.71 V ~ 3.63 V |
| DSC1001CC1-047.3333 | Microchip有源晶振 | DSC1001 | MEMS | 47.3333MHz | CMOS | 1.8 V ~ 3.3 V |
| DSC1030BC1-008.0000 | Microchip有源晶振 | DSC1030 | MEMS | 8MHz | CMOS | 3V |
| DSC1001BC1-024.0000 | Microchip有源晶振 | DSC1001 | MEMS | 24MHz | CMOS | 1.8 V ~ 3.3 V |
| DSC1033BC1-026.6000 | Microchip有源晶振 | DSC1033 | MEMS | 26MHz | CMOS | 3.3V |
| DSC1001DI1-001.8432 | Microchip有源晶振 | DSC1001 | MEMS | 1.8432MHz | CMOS | 1.8 V ~ 3.3 V |
| DSC1033CI1-048.0000 | Microchip有源晶振 | DSC1033 | MEMS | 48MHz | CMOS | 3.3V |
| DSC1033CI1-024.0000 | Microchip有源晶振 | DSC1033 | MEMS | 24MHz | CMOS | 3.3V |
| DSC1033DI1-012.0000 | Microchip有源晶振 | DSC1033 | MEMS | 12MHz | CMOS | 3.3V |
| DSC1033DI1-036.0000 | Microchip有源晶振 | DSC1033 | MEMS | 36MHz | CMOS | 3.3V |
| DSC1001CI1-027.0000 | Microchip有源晶振 | DSC1001 | MEMS | 27MHz | CMOS | 1.8 V ~ 3.3 V |
| DSC1033CI1-050.0000 | Microchip有源晶振 | DSC1033 | MEMS | 50MHz | CMOS | 3.3V |
| DSC6001CI1A-011.0592 | Microchip有源晶振 | DSC60XX | MEMS | 11.0592MHz | CMOS | 1.71 V ~ 3.63 V |
| DSC1001CI2-024.0000 | Microchip有源晶振 | DSC1001 | MEMS | 24MHz | CMOS | 1.8 V ~ 3.3 V |
| DSC1033BE2-024.0000 | Microchip有源晶振 | DSC1033 | MEMS | 24MHz | CMOS | 3.3V |
| DSC1001DI2-038.4000 | Microchip有源晶振 | DSC1001 | MEMS | 38.4MHz | CMOS | 1.8 V ~ 3.3 V |
| DSC1001CI5-033.3333 | Microchip有源晶振 | DSC1001 | MEMS | 33.3333MHz | CMOS | 1.8 V ~ 3.3 V |
| DSC1101DM2-012.0000 | Microchip有源晶振 | DSC1101 | MEMS | 12MHz | CMOS | 2.25 V ~ 3.6 V |
| DSC1001DE5-018.4320 | Microchip有源晶振 | DSC1001 | MEMS | 18.432MHz | CMOS | 1.8 V ~ 3.3 V |
| DSC1101AI2-040.0000 | Microchip有源晶振 | DSC1101 | MEMS | 40MHz | CMOS | 2.25 V ~ 3.6 V |
| DSC1101AI2-080.0000 | Microchip有源晶振 | DSC1101 | MEMS | 80MHz | CMOS | 2.25 V ~ 3.6 V |
| DSC1101AI2-064.0000 | Microchip有源晶振 | DSC1101 | MEMS | 64MHz | CMOS | 2.25 V ~ 3.6 V |
| DSC1124CI5-100.0000 | Microchip有源晶振 | DSC1124 | MEMS | 100MHz | HCSL | 2.25 V ~ 3.6 V |
